3.20 চল তড়িৎ Kirchoff's voltage law practice problem
Автор: Apurbo physics
Загружено: 2020-05-06
Просмотров: 121452
চল তড়িৎ
পদার্থ বিজ্ঞান ২য় পত্র
৩য় অধ্যায়
Gustav Kirchhoff’s Voltage Law is the second of his fundamental laws we can use for circuit analysis. His voltage law states that for a closed loop series path the algebraic sum of all the voltages around any closed loop in a circuit is equal to zero. This is because a circuit loop is a closed conducting path so no energy is lost.
In other words the algebraic sum of ALL the potential differences around the loop must be equal to zero as: ΣV = 0. Note here that the term “algebraic sum” means to take into account the polarities and signs of the sources and voltage drops around the loop.
This idea by Kirchhoff is commonly known as the Conservation of Energy, as moving around a closed loop, or circuit, you will end up back to where you started in the circuit and therefore back to the same initial potential with no loss of voltage around the loop. Hence any voltage drops around the loop must be equal to any voltage sources met along the way.
