SPECIFICATIONS
Dimensions
Floor Length 14'10''
Overall Length 19'8''
Exterior Width 84-3/8''
Exterior Height w/Optional 13.5M A/C 9'10''
Interior Height 78''
Convertible Dinette Bed Opt. 36'' X 59''

Weights
Gross Dry Weight 2600 Lbs.
Hitch Dry Weight 250 Lbs.
Axle Weight 2350 Lbs.
Cargo Carrying Capacity 1100 Lbs.
GVWR 3700 Lbs.
Capacities
Fresh Tank 26 Gal
Grey Tank 26 Gal
Black Tank 26 Gal

Other
Refrigerator 5 Cu. Ft.
Propane 1-5 Gal
Furnace 14.3M
Sleeping Capacity 2/3
Tire Size ST205/75R14

STANDARD EQUIPMENT

BATHROOM
Black Tank Flush
Ducted Heat
Marine Toilet - Hand - Plastic
Skylight - Dual Pane

BEDROOM
Dlx Queen Innerspring Mattress w/Pillow Top & Bedspread
LED Reading Lights

CONSTRUCTION/INSULATION
Aluminum Framed Sidewalls/Floor/Ceiling
Azdel Interior Panel Walls
Block Foam Insulation Throughout
Tapered Exterior Roof Design

ELECTRICAL
12V/USB Charging Port(s)
AM/FM/DVD Stereo W/Interior Speakers
Exterior 12V/120V Patio Outlet/Cable Outlet
Interior/Exterior Bluetooth Speaker
LED Interior Lighting - Ceiling & Under Overheads
LED Patio & Hitch Light - Switched
LED Vanity Lighting Over Medicine Cabinet
Pre-Wired for Roof Air/Fantastic Vent
Pre-Wired for TV Ant/Park/Sat Cable
Single Battery Compartment & Disconnect
Solar on the Side Pre-Wire (Receptacle)
Storage Compartment Lighting
Systems Monitor Panel W/Battery Indicator
TV Antenna HD
Wall Switched Lighting & Thermostat

EXTERIOR
Aluminum Wheels W/Goodyear Radial Tires
Car Cord/Safety Chain Storage Holder
Double Entry Step - 24 Inch w/Step Well Lighting - LED
Exterior LCD Mounting Puck W/Removable LCD Bracket
Exterior Propane Connection
Exterior Wash Station
Fiberglass Front w/TPO Lwr Gravel Guard/Propane Cover
Formed Jewel LED Docking Lights
Keyed-Alike Entry & Storage Compartment Doors
Laminated Fiberglass Bonded Exterior W/Azdel Substrate
LED Tail Lights & License Plate W/Holder
Manual Stabilizer Jacks W/Foot Pad
Radius Acrylic Tinted Thermopane Euro Windows
Radius Cornered Storage Compartment Doors
Roof Vent in Bed & Living Area
Skylight in Galley/Dinette Area
Spare Tire Carrier

FRESH AND WASTEWATER SYSTEMS
Enclosed, Insulated and Heated Fresh Water Tank
Water Heater Gas/Electric W/Boost (Truma)

GALLEY/APPLIANCES & EQUIPMENT
Euro Overhead Cabinetry Design W/Accent Lighting
Flush Mount SS 3-Burner Range w/Cover & BackSplash
Furnace Forced Air 14,300 BTU
Propane Tank 1 Each 5 Gallon w/Gauge
Refrigerator (5 Cu Ft) 3-Way Double Door
Single Sink Undermount w/Pull-Out Faucet & Cover
Stainless Steel Range Hood W/Light & Fan

INTERIOR/DECOR
Combo Screen/Shade on Windows
Lite-Ply Cabinet Construction
Swivel Rockers (1 Swivel Rocker / 1 Swivel Only)
Wall Clock & Key Hanger

OPTIONAL EQUIPMENT

BEDROOM
Bed Maid
COLORS - INTERIOR
Interior - Java
Interior - Platinum
Interior - Royal

ELECTRICAL
A/C - Coleman 13.5 Wall Control
A/C - Coleman 15 Wall Control
A/C - Dometic 10K Low Pro Wall Control
Backup Camera w/Vehicle Monitor
Fantastic Roof Vent - Remote Control
Lithium Battery
Solar Panel - 190 Watt
Solar Pre-Wire
TV LED 28 Inch 12 Volt

EXTERIOR
All-Weather Package
Awning 12' Power w/LED Lighting
Electric Tongue Jack
Exterior - Mountain Scene Graphics
Keyless Entry
Lift Kit (2-5/8 Inch)
Pull-out Storage Tray
Revolution Entry Step 25 Inch
Slide-Out
Spare Tire
Swing-Out Entry Assist Handle

GALLEY/APPLIANCES & EQUIPMENT
3-Burner High Output Range W/Oven
Microwave Convection
Microwave Oven
Match your trailer and tow vehicle correctly. See your dealer for assistance.
