Ford Excursion / F250 - F550 1998-2004 Wheel Bearing Replacement
Автор: MotorLeague
Загружено: 2024-11-11
Просмотров: 3057
Update: The thrust washers behind the locking hub were installed incorrectly when I purchased the truck. The plastic nut actually goes between the two metal washers. Not as shown in the video.
Video shows step by step how to replace the front wheel bearings on a 2003 4x4 Ford Excursion. The process will be the same for all 4x4 super duty trucks, F250, F350, F450 and F550 from 1998-2004.
One thing to note when ordering the new bearings is the difference between the coarse and fine thread options. Most pre 2003 trucks will be coarse thread from the factory while 2003 and up will be fine thread. Coarse threads will be 14x2.0 and the fine thread will be 14x1.5. Timken part number - SP580205
Chapters:
00:27- Ordering the right bearings
02:38 - Removing bakes
05:03 - Removing locking hub (Thrush washers were installed incorrectly)
06:58 - Removing tie rod
07:54 - Removing bearing
10:40 - Assembling new bearing hardware
11:33 - Installing new bearing (Dust shield is on backwards)
12:57 - Assembling locking hub (Thrush washers go on either side of the plastic washer)
15:00 - Assembling brakes
18:44 - Assembling tie rod
#ford #wheelbearing #powerstroke
