Davenport 5 Spindle Model B Oversize Auto Screw Machine, Ref.#2-591 (SOLD)
Автор: New England Industrial Machinery
Загружено: 2009-09-25
Просмотров: 13209
Davenport 5-Spindle Automatic Screw Machine Ref.#2-591
Model B Oversize
Serial No. 13483 New 1996
Maximum Collet Capacity:7/8" Diameter
Maximum Length of Feed:3"
Maximum Turning Length:2.5"
Spindle Speeds:500 - 4500 RPM
Overall Machine Dimensions:40" x 82" x
Required Floor Space with Stock Reel:40" x 177"
Machine Weight, Approx.:4,000 Lbs.
Equipped With:
4th Position Adjustable Cross Slide
Internal Recessing Attachment
Stock Reel & Stand with Tamer
Full Machine Enclosure
Wire Case Carrier Liner
Rotary Support Spindle
Aercology Mist Collector
Threading Attachment
Pick-Off & Burring
Misc. Speed Gears
Misc. Feed Gears
Chip Conveyor
Misc. Tooling
Collets
Cams
7.5 HP Main Motor 575/3/60
