Big Improvements to the CNC Enclosure - Shapeoko Pro XXL
Автор: SethCraft Shop
Загружено: 2025-06-06
Просмотров: 1444
The Shapeoko Pro XXL CNC machine enclosure that I made worked well but had two big issues. Number 1 it was too short and number 2 there was no dust collection system. Both of those have been fixed in this update.
The enclosure height was increased by 7" to allow the needed room for the dust collection hose. The hose needs to stay upright as the machine works so I made a hose adapter that mounts on the Z axis stepper motor. The hose needed to pass through the side of the enclosure to allow air flow. To fix this issue I made a flange adapter with tube to pass through the plywood and still make a tight seal.
Check out the CNC Wall Pass thru:
https://sethcraftshop.com/products/cn...
The Hose Adapter Mount:
https://sethcraftshop.com/products/cn...
