everything about the winding of electric motors || Full rewinding 45kw 1500rpm ABB
Автор: coil_magnet
Загружено: 2024-02-25
Просмотров: 2945
Hello, dear friends
Today's video is related to the winding of the 45kw 1500rpm electric motor from ABB brand.
The number of grooves is 48
Groove length 22.5cm
The type of insulating paper used is NOMEX 0.25MM
The number of bobbins is 12
The weight of each bobbin is 2.2 kg
Vern, the total wire used is 26.4kg
The size of the lacquered wire used is 5 x 1.25 mm
Thank you for your support, dear ones.
00:00 Removing defective wires and preparing the electric motor for winding
07:00 Re-insulation of electric motor
08:46 Winding of electromotor coils
09:52 Inserting the coils of the electric motor into the slots of the stator
20:51 Electric motor threading
24:28 Connecting the coils of the electric motor
30:20 Electric motor threading
