Using Scan Data To Help Design Parts for 3D Printing | 3D Printed Ear Bud Shelf with
Автор: Learn Everything About Design
Загружено: 2023-04-03
Просмотров: 13548
In this video we are going to problem solve using some scan data, a 3D printer and Fusion 360.
The Problem: Ear bud charging case needs a better place to sit.
The Solution: 3D Scan the plug and ear bud case and use Fusion 360 form tools and a 3D printer to fix that.
We will be using scan data created with a Shining 3d Einscan Pro HD that was on loan. Using a standard Samsung wall plug and a Raycon Ear bud charging pod we will create a design that fits on the plug and gives the charging pod a nice place to rest out of the way.
If you want to follow along you can download the Fusion file which contains the scans of the charging plug and pod.
https://a360.co/3nGJI3G
If you have any questions or have video ideas please leave a comment or send me an email support@caducator.com
00:00 Introduction
00:18 What are we designing?
04:17 Review of the Version 1 Part
05:54 Download the Dataset
06:45 How to start a form on a scan
09:45 Form Base Shape Details
17:23 Adding Form Edges and Bevels
28:05 Adding and Adjusting Edges to Match the Shape
36:35 Subdividing the Form before a Thicken
39:10 Form Thicken and Shelf Creation
53:15 Fusion 360 3d Print Slicer
1:00:48 3D print Timelapse
1:00:52 Part Review and Conclusion
