Making an EPROM Adapter and Burning Amiga Kickstart ROMs - TL866 MiniPro

This project was kindly sponsored by https://www.PCBWay.com! Today we are going to bring a Commodore Amiga A600 Back to life. It has a broken Kickstart ROM, but my Minipro TL866 doesn't support the 27C400 EPROM devices. We're going to build an adapter, then copy and burn the data to a new EPROM. Finally we'll test to see if the broken Amiga boots!

Please help support Mark Fixes Stuff at   / markfixesstuff   - Even the smallest pledge helps!

PCBWay board link: https://www.pcbway.com/project/sharep...
Creator forum here: https://circuit-board.de/forum/

00:00 - A Broken Amiga A600!
00:28 - A Kickstart ROM with missing legs!
00:40 - EPROM Programmer and EPROMs.
00:51 - Incompatible TL866 EPROM problem.
00:59 - The solution to burning an Amiga Kickstart Eprom
01:11 - Mark Fixes Stuff Intro
01:16 - Sponsor Thanks
01:30 - About the Adapter and the Designer
01:43 - Supported EPROMs - 27C160, 27C322, 27C400 and 27C800
01:54 - How the EPROM adapter board works
02:13 - Building the Board - Step-by-Step.
11:11 - The EPROM adapter is complete
11:19 - Testing the EPROM adapter with the TL866
11:26 - Fixing the broken pins on the original Amiga A600 Kickstart ROM
11:41 - Soldering temporary legs onto the ROM
12:37 - Dumping an Amiga Kickstart ROM using the EPROM adapter on the TL866.
14:06 - Writing the Amiga Kickstart ROM to a 27C400 EPROM.
16:41 - Trying out the burned EPROM in a real Amiga A600
17:05 - Installing the EPROM in an A600
17:17 - Hooking up an Amiga Disk Drive
17:31 - Power On.
17:37 - Will an Amiga boot from a Kickstart ROM burned to an EPROM?
17:45 - Burned EPROM Amiga Kickstart - Test result
17:49 - Wrap up and further plans.
18:04 - Patreon Thanks
18:15 - Viewer thanks and Further Watching!
