Taig CNC Mill - Custom Enclosure Demo - FOR SALE

FRONT LEXAN DOOR IS NOT INCLUDED ANYMORE

Reply to the CL post if interested in purchasing:
https://phoenix.craigslist.org/evl/tl...

Taig 5019DSLS CNC Mill

Used for a total of 1 year. Selling because I now have a much higher-end machine that I use. A great machine to learn CNC machining on, it taught me a lot.

Enclosure Features:

Wooden Cabinet with Rockwool insulated walls
Aluminum / Stainless Steel Basin
Extra Large Dual Pane Polycarbonate Window
Flood Cooling
Two Ventilation/Cooling Fans
LED Work Light
Laptop with RAM Mount Stand
Controls consolidated to the front of the machine
Sealed off zone for the control boxes
Casters
Requires only a single 120V 15A appliance extension cord

Modifications:

Modified from belt drive to chain drive for increased reliability
Added Waycover for the X Axis Motor

Stock Description:

CLOSED Loop Optical Encoder Feedback Control CNC Micro Mill with BallScrews on each axis with Nema 23 motor mounts, stepper motors, control system, and MACH3 software.

5019DSLS Maximum Travel: X = 11.375", Y = 5.5", Z = 6.0"
5019DSLS Table dimensions 3 1/2 x 18 1/2 inches

Maximum Speed: 100 in/min.
HARDENED ER16 Spindle in Mill Head
Max cutter shank : 3/8" (with 3/8" ER16 collet)

Maximum Z distance to table : 8.0"
Z-Axis swivel 90 degrees
Mechanical Resolution: 0.0005 in.
Electrical Resolution: 0.00013 in.
Spindle Speeds: 1100-11000 RPM.
Rigid square tubular steel base and column construction.
X Axis - Hard Anodized Table with 45 deg. dovetail sliding on steel ways
Y Axis - Precisionly ground prismatic 90 deg. steel rail ways.
Z Axis - Steel box ways

Original Order:

1 MicroMill DSLS 3000AB (5019DSLS) # 1AB
(with Anti-Backlash Ball Screw option)
1 3/4 HP Variable Speed Spindle
1 XYZ Home Switches
1 USB Module
1 Mach 3 Software License
1 Package Tooling (below)
1 Milling Cutter Set (1/16,3/32,1/8,5/32,3/16")
1 2225 Milling Vise
1 1159 Spare Belt
1 1310 Spindle Wrench
1 1140ER Chuck Arbor
1 1091 Jacob's Drill Chuck
1 ER-16 Collet Set (1/8, 3/16, 1/4, 3/8")
