Modelling Of Power System Network Generation To Distribution by using SCILAB
Автор: Competitive exam library
Загружено: 2026-01-09
Просмотров: 22
Описание:
Simulate a simple single-line power system consists of:
A generator of 11 kV,
Connected to a load through a transmission line and a distribution line.
The impedances of each section are as follows:
Component Impedance (Ω)
Generator internal impedance Z_g=0.5+j1
Transmission line impedance Z_t=2+j4
Distribution line impedance Z_d=1+j2
Load impedance Z_load=10+j5
Find:
The total impedance of the system.
The line current.
The voltage across the load.
The complex power delivered to the load.
The total system losses. By using SCI lab
