Junkkari HJ-200G Wood Chipper Part 5

Tractors main hydraulic pump is too powerful for the chipper. I am now using tractors steering hydraulic pump NSH-10 (НШ 10) , that produces about 22l/min (5.8gpm).

The HJ200G model requires hydraulic oil from the tractors hydraulic system 5-20l/min (1.3 - 5gpm). So it should be all good now?!

Also testing with vented Big-Bag's: 90x90x175cm, 4 loops, SWL 1000kg, top skirt, bottom spout

HJ-200G Wood Chipper Part 1:    • Junkkari HJ-200G Wood Chipper Part 1
HJ-200G Wood Chipper Part 2:    • Junkkari HJ-200G Wood Chipper Part 2
HJ-200G Wood Chipper Part 3:    • Junkkari HJ-200G Wood Chipper Part 3
HJ-200G Wood Chipper Part 4:    • Junkkari HJ-200G Wood Chipper Part 4
HJ-200G Wood Chipper Part 5:    • Junkkari HJ-200G Wood Chipper Part 5

JUNKKARI HJ 200G TECHNICAL SPECIFICATONS

Machine type: Junkkari Hj200 G
Cutter flange dia.: 25" (63cm)

Cutter flange weight kg: 100
Flange speed rpm: 540-1000
No. of cutter knives: 4
Chip size: 0.15 - 0.60" (3 -18mm)

Stem dia. (max): 7½" (19cm)

Cutting efficiency cu.m/h: 4-10

Power requirement hp/kW: 27-70/20-50
Weight of basic model kg: 560
Height in transport position cm: 90"(230cm)
Feed orifice size: 7½"x 7½" (19cm x 19cm)

-
