Full METAL | Fully MADE IN TN | Electric Ozotec Bheem Hill & Water Ride | Racing 1 Lakh Cash Prize

Bheem Launch Event Video -    • Longest Range in World 515 Kms/Charge Ozot...

*Ex. Showroom price = 65,990/- (inclusive of GST, Fame-2 subsidy, offers.)
*Base Variant

Performance-
Max Loading capacity 350Kg
Motor Mount Mid-Mount
Max Power 3Kw
Max torque 22Nm
Top speed 65Kmph
Gradeability 22 degree
Riding modes 1,2,3 & Reverse
Motor type BLDC/PMSM
Ingress protection (motor) IP67
Ingress protection (controller) IP65


Battery Options-
Battery Pack Casing Pressure Die Cast (PDC) Aluminum Alloy Pressure Die Cast (PDC) Aluminum Alloy
Ingress protection (Battery) IP67 IP67
Battery Chemistry LFP Li-Ion
Battery Nominal Voltage 48V 55.5V
Cell Size 32700 21700
Max Range per Charge 215Km 515Km
Charging time 4.5Hrs 4.5Hrs
Fast Charging Optional Optional
*Battery capacity (options available) 1.75Kwh,2.6Kwh,4Kwh 5Kwh,7Kwh,10Kwh


Chassis and Transmission-
Chassis type Dual Steel Tubular
Transmission Type Chain Drive / Belt Drive (Optional)


Tyres & Wheels-
Wheel Type Spoke
Wheel size (F/R) 16” X 2.75”
Tyre size (F/R) 16 X 2.50 / 16 X 2.75 / 16 X 3.00


Brakes-
Brake type Combined Braking system (CBS)
Brake Front Drum 130 mm
Brake Rear Drum 110 mm


Suspension-
Front Suspension Telescopic fork
Rear Suspension Heavy Duty - Dual Shock absorber


Features-
Connectivity Bluetooth
USB Charging port Yes


Warranty-
Warranty up to 7 Years*


Smart App Functions-
Speedo Meter
Battery % display
Distance to empty
Trip Meter
Google Maps
Document viewer
Audio Player
Video Player
Weather Forecast
