Creo Parametric - Pairs Clearance Analysis and Motion Analysis
Автор: Creo Parametric
Загружено: 2023-12-20
Просмотров: 1687
This Creo Parametric tutorial shows how to create a Pairs Clearance analysis to measure the distance between two components, and then a Motion Analysis to track the separation during a mechanism analysis. When I tried to create a Feasibility Study to drive the minimum separation to a specified distance, it would not work until I used a Sensitivity Analysis to figure out a better initial range for the dimensions.
This video is based on an exercise from the Pro/ENGINEER 2001 training class "Consistent Innovation with Behavioral Modeling."
For more information, visit https://www.mcaeconsulting.com.
If you learned something from this video, please give it a thumbs up. If you like this video, please click the Subscribe button to be informed when new videos are uploaded. Also please write a comment if you would like to see more videos like this.
Feel free to share or embed this video, and add it to your playlists.
Creo administrators, you can share the Creo Parametric channel with your users as a training tool:
http://tinyurl.com/CreoParametric
Thanks,
Dave
