12" NIKON MADE IN JAPAN BENCH TYPE OPTICAL COMPARATOR

Check our site for photos or more info:
https://www.machineryvalues.com/inven...

12" NIKON HIGH-PRECISION MADE IN JAPAN BENCH TYPE VERTICAL PROJECTION OPTICAL COMPARATOR

** QUADRA-CHEK 200 DRO, WITH PROGRAMMABLE GEOMETRIC FUNCTIONS **

S/N: 1100310 NEW: 2000

SPECIFICATIONS:
SCREEN DIAMETER:........................................ 12"
STAGE EQUIPPED WITH MACHINE ............................ 6" x 4"
MAXIMUM HEIGHT OF WORKPIECE ON STAGE:................... 4"
CHART ROTATION:......................................... 360 DEGREES

FLOOR SPACE: ........................................... 16.1"W x 25.5"D x 40.8"H
WEIGHT: ............................................... 175 LBS. (APPROX.)


MACHINE FEATURES:
ERECT & UNREVERSED IMAGE
MACHINE ACCOMODATES A SPECIMEN HEIGHT UP TO 4"
HIGH/LOW INTENSITY 24V/150W TUNGSTEN HALOGEN PROJECTION
BUILT IN SURFACE ILLUMINATION
HIGH/LOW INTENSITY 24V/150W TUNGSTEN HALOGEN PROJECTION
BUILT-IN DIGITAL READOUT FOR THE PROTRACTOR
ROTATING TURRET MOUNT HOLDS THREE PROJECTION LENSES
ELECTRICAL - 1/60/120 VOLTS AC


EQUIPPED WITH:
QUADRA-CHECK 200 DIGITAL READOUT SYSTEM, WITH PROGRAMMABLE GEOMETRIC FUNCTIONS
HIGH-PRECISION ACU-RITE GLASS SCALES
TWO LENSES, 10X & 20X MAGNIFICATIONS
6" X 4" STAGE TRAVELS:
SURFACE AREA 13.8" x 9.5"
STAGE GLASS DIMS. 8" x 5.7"
LOADING CAPACITY 15 LBS.
NIKON ROTATING TABLE TYPE 3 (S/N: 1004775), FOR 6" x 4" STAGE:
TABLE DIAMETER 8"
GLASS INSERT DIAMETER 6.5"
ROTATION RANGE 360 DEGREES

** SUPERB CONDITION & APPEARANCE **
** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE **
