KTS - Bolted Gusset (11) in Tekla Structures
Автор: Keyack Technology Solutions
Загружено: 2024-01-03
Просмотров: 4382
Описание:
This video shows how to use Bolted Gusset (11) system component in Tekla Structures to connect HSS bracing to a column and base plate as well as an HSS brace to the bottom flange of a beam.
Chapters
00:00 - Apply the Connection
01:56 - Adjust the Brace Setback and Lap
06:06 - Set the Slot Size and Length
09:41 - Define the Weld Sizes and Corner Clip
12:58 - Adjust the Size of the Gusset Plate
15:51 - 2 Braces to Bottom Flange of Beam
18:19 - Connection (60) instead of (11)
