BSD ALVX V3 Unboxing & Frame Build @ Harvester Bikes
Автор: harvesterbmx
Загружено: 2018-04-24
Просмотров: 2983
Alex D’s ALVX frame is a super tech street steed with the steepest headtube angle of any of our frames and probably the shortest rear end available on any 20” frame, this beast is designed with technical moves in mind. Updated for 2017 with built in chain tensioners.
The ALVX frame features:
– Super short rear end slammable to 12.5”
– New chain tensioners added for 2017
– Extra wide rear end for up to 2.4” tyres
– Curved ends on stays for peg clearance
– External gussets
– No brake mounts.
Spec
Toptube lengths:
20.3″, 20.6″, 20.8″ and 21″
Headtube angle:
75.5°
Seattube angle:
71°
Rear end length:
12.5″ – 13″
BB Height:
11.7″
Standover height:
8.7″
Weight:
5 lbs
Colours:
Black
