Inside a High-End Vintage Tektronix 7904 Oscilloscope, PCBs from 1968-1974 (unusual construction)
Автор: Lantertronics
Загружено: 2022-11-06
Просмотров: 4187
Описание:
UPDATE: Y'all have convinced me to try my hand at restoring these. I will document my progress. Thanks for the many offers of information and assistance!
There's some construction techniques used here, like IC pins mounted into the PCB itself and a surface mount part that isn't soldered, but press fit onto the PCB using pressure from screws, that I've never seen before. And all the transistors are socketed!
Support this channel via a special purpose donation to the Georgia Tech Foundation (GTF210000920), earmarked for my work: • [OLD] Support This Channel via a Special P...
