ITC#89:- Atari 2600 6-switch UAV Install Process (NTSC)

This video was originally filmed about 2 years ago and some of the original video/audio was lost in that time. But it has been a long time coming and I'm glad to finally release and share my install process for UAV setups for both light and heavy 6-switch Atari 2600 NTSC consoles.

This install process differs greatly from the common method that attaches the UAV piggyback onto the 4050 IC chip that is present on these model 2600s. The 4050 in addition to handling the video buffering, also provides the circuit for the fire button triggers on the controllers and isn't always in a socket on these models. Therefore I don't use this method personally and use the point to point method shown in this video as it doesn't pose any risk to the TIA or 4050 IC chips in the console.

-----------------------
Time Stamps:-
00:00 - Intro & Video Purpose
01:37 - Tools Needed for the Project
03:05 - Disassembling the 2600 6-switch console
07:10 - TIA to UAV signal/wiring diagram
08:40 - UAV Pre-install board prep
09:44 - UAV installation to main board
10:59 - Disabling R213 to prevent color issues through UAVk
12:12 - Getting audio wired up
14:20 - UAV + audio output testing
15:21 - Outro

-----------------------
Parts & Tools Needed:-
UAV basic board
Audio/Video output cabling or jacks
#2 Phillips head Screwdriver
Wire strippers
Soldering Station
sections of various wire lengths as needed
Flush Cutters
Cleaning supplies (toothbrush, cotton buds, & IPA)

Optional/Possible Additional Tools:-
Small needle nose pliers
Tweezers
De-soldering braid/wick
10µf 16v electrolytic capacitor (for audio - Optional)
4 to 8k 1/4w 5% resistor (for audio - Optional)

-------------------------
UAV boards can be purchased from The Brewing Academy Store listed below:
https://thebrewingacademy.com/

-------------------------
A printable and detailed installation PDF guide is available from the link below:
https://tinyurl.com/yeyncckh

-------------------------
