Overkill CNC Router Upgrade Part 5 - Chatter free Z-Axis Design
Автор: scratchbuilt designs
Загружено: 2025-06-14
Просмотров: 19995
My DIY CNC router build continues with the Z-axis assembly. I explain the design considerations and the pros and cons of moving rails vs. moving blocks designs for Z-axes and the impact on overall rigidity.
Furthermore, I show the complete assembly and a few tips and tricks for ball screw assembly.
This is part 5 of a series, documenting the build of my latest design of a DIY woodworking router.
Here is the link to the first parts:
• Overkill CNC Router Upgrade
Chapters:
00:00 Intro
00:48 Z-Axis Design Comparision
05:40 Making of the Parts
09:47 Part overview
10:26 Assembly - Part 1
14:45 Fixed Bearing Block Mistakes
17:52 Assembly - Part 2
19:32 Greasing Concept
21:10 Mounting to Gantry
22:18 Timing Belt Tension Adjustment
23:57 Tramming
24:53 Spindle
26:10 Cable Management
27:39 Outro
