Building a Delta Loop Antenna For The 30m Band, Part 1.

Since my 6m Delta Loop seems to work pretty well I decided to build one for the 30m band to be used with my Spiderbeam 12m mast. Unfortunately I cut it too short. The balun works well. I need to try a quarter wave of 75 Ohm coax instead, just for testing... Note that fed a one lower corner polarisation is vertical. Stay tuned for part two...
