Learn Features of 8051 Development Board | Atmel AT89S52 Microcontroller Project Kit | MY TechnoCare

#8051DevelopmentBoard with ZIF Socket. This Project Kit Support AT89S51, #AT89S52, P89V51RD2, etc. 40-Pin DIP Chip. If you are learning #microcontroller programming and want to make a project based on #8051 microcontrollers then this board will help you. With this board, you can develop and prototype with any of 8051(AT89S51, AT89S52, P89V51RD2, AT89Cxx) 40 pin microcontrollers. Because The board has 1.5 Amp bridge rectifiers allows this board to be powered with both AC and DC power supply adapters. The board having an RS232 Serial port for flashing the P89V51RD2 (NXP) microcontroller and also it is used for interfacing GSM module, GPS module, and an RFID module. Furthermore, there is a 5V, 12V, GND power bus which allows to power external peripherals module.

Watch Other Related Videos:

Features of USB ISP Programmer for 8051/AVR:
   • Learn Features of USBasp ISP Programmer fo...
Features of IR Sensor Module:
   • Features of Infrared IR Proximity Sensor C...
Features of DS1307 RTC Module (Real Time Clock):
   • Features of DS1307 RTC Module | I2C Real T...
Features of Relay Module:
   • Features of 5v Relay Module Circuit for Ar...

Subscribe to MY TechnoCare Channel:
   / @mytechnocare

You Can Get this Kit From Below Link:
https://www.mytechnocare.com/product/...

Also, Get USB ISP Programmer For 8051 From the Below Link:
https://www.mytechnocare.com/product/...

Features of 8051 Kit with ZIF Socket:
• DIP 40 Pin ZIF (Zero Insertion Force) Socket. For Easy Insert/Remove of IC
• ZIF Socket Protect Your Microcontroller From Damage
• On-board MAX232 Circuit for Easy Communication with a PC & other RS232 serial devices (GPS modules, GSM Modems, etc.)
• High-quality FR-4(1.6 mm) PCB
• On-Board bridge rectifier so the board can accept both AC & DC Input voltages Power supply
• 5 mm Power Plug-in DC Jack | Power ON-OFF switch.
• 5V regulator (LM7805) circuit.
• Power indication RED LED.
• On-Board GREEN USER LED at P2.0 through jumper JP3.
• On-Board Input User Switch P3.3 through jumper JP2.
• On-Board Input External Interrupt Switch (INT1) at P3.3 through jumper JP2.
• On-board Quartz Crystal 11.05892 MHz
• Support AT89S51, AT89S52, P89V51RD2, etc. 40-Pin DIP Chip
• Port Extensions for all PORT with Detailed Labelling for Easy Identification of Pin
• External Pull-Up resistors for Port 0
• On-board ISP connector for loading HEX file into Microcontroller like AT89S51/52 etc.
• Extra Vcc bus (5V and 12V) & GND bus for POWER Supply to the External Peripheral.
• Four 3mm mounting hole for Easy Mounting
• On-board Reset button.
