⭐ Simulation of the Impact Phenomena - ANSYS Tutorial ⭐

֍ In this tutorial, we will learn how to do an impact analysis using ANSYS Explicit Dynamics. We use nonlinear materials for impact analysis. Through this tutorial, we will simulate the impact of a bullet on a steel wall. The dimensions of the model are chosen based on a calibre 22 bullet.
We will find out about the steel wall resistance to the fired bullet, which hits it at a speed of 900 meters per second in a perpendicular direction. We can also see the directional deformation of the wall and exactly how much our steel wall has deformed perpendicular to its surface and measure how much the bullet has penetrated the steel plate. We will learn how to set up an impact analysis in ANSYS Workbench Explicit Dynamics and extract desired outputs.

▼ ▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄ ▼
