EASY AND CHEAP IBM Model M Cable Replacement and PS/2 cable Coiling!

Easy and cheap PS/2 cable replacement on a IBM Model M keyboard. Factory cable is broken or is in bad condition? In this video, I show how to coil a cheap straight cable to replace the old one. I also show how to open a IBM Model M (how to dismantle a IBM Model M). Than I soldering very easily the new one on the keyboard.

Click and Thock is a Youtube channel all about keyboards sound! No talking, just clicks and thocks!
I Sound Test different Vintage Keyboards and Switches! I also Review, Restore and Dismantle Vintage Keyboards. Finally, I test different Modern Switches, Cases, Plates, Keycaps and other components to compare the effect on sound!

Here my email if you want to contact me in private : clickandthock@gmail.com

I'm not sponsored, so like and sharing the video can help me. Don't forget to subscribe to the channel!! If you have questions or want to share something, write it in the comments below, I read EVERY one of them!

Thanks for watching!

If you want, you can add my DISCORD Server:
  / discord

Facebook: https://www.facebook.com/profile.php?...
Reddit:   / clickandthock
Instagram: clickandthock

00:00 - Intro
00:17 - Presentation
00:38 - Restoration planning
01:24 - Coiling the cable
02:47 - IBM Model M dismantle
03:36 - Cable soldering
04:35 - Final result
05:01 - Final


That video have 2 parts. The in the first one I coil the cable to give it a vintage look. I use a heater gun, make sure it's hot enough. Hair dryer is not hot enough. But be careful to not stay to long at the same place, the cable will melt!
I heat it for about 6-10 minutes and I immediately put it in the freezer for 30 minutes. You have to wait about 1 hour after before you remove the tape.
IN the second part, I explain how to dismantle a Model M mechanical keyboard and how to connect the cable to replace the old one.

It's an easy way to give a vintage look to a new cable. New PS/2 cable have 6 wires inside, Model M have 4 wires and the colours doesn't match... I tried to soldering the wires directly but I could not find a wire match that work. Si I come with this solution. Removing almost all the old cable, but keep the original PS/2 connector to the keyboard side to plug it to a female PS/2 port on the new cable. Than I hide the connection inside the keyboard.
You could keep the connection outside the key board. The coiled cable would be detachable. But I personally wanted to keep the vintage look of the keyboard.

I choose to solder the wires before heat shrink them. But you could just twist them together. Just make sure no unstripped wires touch each other. Make sure they are isolate.
