Triumph TR4 - Front Suspension Assembly: Part 2 | Roundtail Restoration

It wasn't easy and there were a lot of false starts, but I finally got the front suspension back together. This is part two is what will probably be a three part series in putting one side of the front suspension all back together for a Triumph TR4. Thanks for watching and I hope it helps!

Link to front suspension hardware: https://docs.google.com/document/d/1D...

Want to see all of the body restoration of my 1966 Triumph Spitfire? This playlist starts shortly after engine rebuild and goes through completion:    • Triumph Spitfire Restoration

Want to see my engine rebuild of my 1147cc Triumph Spitfire motor? This playlist covers most of it:    • Triumph Spitfire Engine Rebuild

Want to see the on-going restoration of of my 1964 Triumph TR4? This playlist is it so far:    • Triumph TR4 Restoration

Want to see my on-going engine rebuild of my Triumph TR4 motor? This playlist is it so far:    • Triumph TR4 Engine Rebuild

Want to see other random technical videos, not exclusive to my Triumphs? (like generator testing)?    • Technical Videos

00:00 - Intro
00:24 - Discussion
01:27 - Spring & Spring Pan Installation
02:58 - Installing the Spring Compressor
04:31 - Compressing the Spring
05:43 - Installing Lower Wishbones
06:34 - Trunnion Installation Prep
08:01 - Trunnion Installation
10:04 - Bolting Spring Pan to Lower Wishbones
12:56 - Finishing Trunnion Attachment
13:57 - Installing Lower Fulcram Brackets
14:41 - Lower Wishbone Stud Challenges
16:01 - Stub Axle Upgrade
18:18 - Removing Old Stub Axle
19:37 - Original vs Uprated Stub Axles
20:09 - Installing New Stub Axle
21:22 - Installing the Vertical Link
23:02 - Upper Ball Joint to Vertical Link
24:10 - Removing the Spring Compressor
24:37 - Shock Absorber Installation
25:34 - Torquing the Stub Axle
26:59 - Rebound Stop Bracket & Abutment Installation
29:00 - I Killed a Lockwasher
29:53 - Highly Calibrated Wood
30:07 - Outro
