Compact® Demo: Pipe Corrosion and Erosion Detection using GUL Screening

Here is a demo video on how GUL Screening can be performed on an 8-inch diameter pipe, Schedule 40 (8.18 mm wall thickness) using the Compact® transducer ring and the Wavemaker® G4mini.

The GUL Screening results show that there is a defect located 14.9 meters from the transducer ring, at the 5 o’clock circumferential location and with an estimated size of 0.84% CSC (cross-sectional area change).

GUL Screening is used to detect corrosion, erosion and other damages in steel pipes using guided waves.

The main applications include accurate detection and location of:
✅ Corrosion under insulation (CUI) ✅ Corrosion under pipe supports (CUPS)
✅ Sludge ✅ Pitting Corrosion ✅ Internal Corrosion ✅ Weld Defects


GUL Screening is ideal for the following applications:
⭕ Road Crossing Pipes ⭕ Buried Pipes ⭕ Wall Penetrations
⭕ Risers ⭕ Caissons ⭕ Tunnel Pipes ⭕ Pipe Bridges


Visit our website (www.guided-ultrasonics.com) to find out more on how GUL Screening can help you tackle the challenges of detecting corrosion and erosion in steel pipes.
💡 For more information, contact us at info@guided ultrasonics.com
