Assembling the Taig 5019CR (CNC Ball Screw Mill)

Assembly video for the Taig 5019CR (CNC Ready Mill)

In this video I take you through the basic assembly of the mill, provide tips that worked for me in assembling the machine. I show you how I dialed in the accuracy of the X Y and Z axis using dial indicators. I showed how you can use a saunders machine works product as a mirror in a pinch :). I connect the motors, wire up the controls and test the mill.

I accept no liability for any damage you do to yourself or your machine. Do your research, use your common sense. This shows I assembled my machine and what worked for me. your mileage may vary

Some of the links below are affiliate links

Taig 5019CR Mill https://taigtools.com/product/micro-m...

NEMA23 381OZ/IN 3.5A MOTOR KL23H2100-35-4BC https://www.automationtechnologiesinc...

Edge Technology Mini Pro Tram System https://amzn.to/3uXPixJ
Grizzly Industrial G9849 - Magnetic Base/Dial Indicator Combo https://amzn.to/3sSTSeW

Machinist Square - https://amzn.to/3rfdXM2

Mobil 100772 Vactra No.2 Way Oil 1 gal - https://amzn.to/3bcgLUv

DEWALT Mechanics Tool Set, 192-Piece (DWMT75049) - https://amzn.to/3rfbJMG



This video includes Royalty Free Music from Bensound
