SolidWorks 2022 Tutorial V-Belt Pulley Design

SolidWorks 2022 Tutorial V-Belt Pulley Designing

Hi and welcome back. Today I am going to show you how to design a V-Groove pulley using SolidWorks 2022. By watching this tutorial, you will learn how to design a pulley by using SolidWorks.

By watching this tutorial, you will learn the use of SolidWorks tools like the sketch, line, circle, fillet, smart dimensions, circular pattern, mirror, etc. You will also learn the use of feature tools, like extrude and extrude cut. Hope you will stay connected with us and continue learning advanced part modelling by SolidWorks 2022.

We will draw the half sketch first and mirror it about the centerline. In this way, we can reduce our effort and save time. Then we will use revolve command to convert the sketch into 3D Pully. Then we will use one sketch to cut the holes and the key slot. Hope you will love the way we design the pully by using SolidWorks 2022.

If you like this tutorial, please don’t forget to subscribe to my channel. Because your engagement encourages me to upload new tutorials. Please also let me know through comments if this SolidWorks 2022 tutorial helps you.

Thanks for your time.
