Abaqus Tutorial: Cylindrical Shell Under Shell Edge Pressure | Static FEA with Shell Elements

In this Abaqus tutorial, we simulate a cylindrical shell subjected to shell edge pressure using static finite element analysis (FEA). This tutorial demonstrates how to model thin-walled cylindrical structures with shell elements, and apply edge pressure loads accurately—an essential approach for analyzing pipes, tanks, and pressure vessels.

You'll learn how to build a cylindrical shell model, assign shell properties, apply shell edge pressure correctly, and interpret stress results in static loading conditions.

Chapters:
Start 0:00
Intro 0:10
Part 1:04
Property 1:45
Assembly 3:07
Step 3:18
Load 3:43
Mesh 4:45
Job 4:54
Visualization 5:06

Topics Covered:
✅ Modeling cylindrical shell structures in Abaqus
✅ Applying shell edge pressure in static simulations
✅ Understanding stress distribution in thin-walled cylinders
✅ Using shell elements for efficient FEA
✅ Post-processing stress and deformation in pressure-loaded shells

This tutorial is perfect for learners and engineers involved in pressure vessel design, shell mechanics, and thin-walled structure simulations in Abaqus.
