How To Make a Printed Circuit Board (PCB) using Ferric Chloride and Maker pen

In this video, I have shown you how to make a circuit board using plain single side copper PCB With etching ferric chloride acid which is very simple and easy method. Just print the PCB layout on permanent maker and follow the video.
Note:-
1: 2 for ferrous chloride and water ,example 50mg ferrous and 100ml water
-------------------------------------------------------------------------------
Download another Circuit diagram and detail - https://goo.gl/KuHZZN
-------------------------------------------------------------------------------
the component is using
1) Ething ferrous chloride
2) single side copper PCB board
3) acetic acid (or) Thinner (or) pertrol
4) water
