Can you replace your C64 PLA for under $3?

Bad PLA chips (MOS 906114-01) are a super common problem for the "breadbin" Commodore 64 machines. There are replacements around but they aren't that cheap. How about one you can build yourself at home for under $3?

The GAL-PLA has been tested on longboard PCB 326298, 250407, 250425 and the SX64 with no compatibility issues or modifications required. Tested with Super Zaxxon, 1541 Ultimate II and Easy Flash 3 with no issues on both NTSC and PAL machines.

0:00 - GAL-PLA Overview
10:57 - Testing the GAL-PLA with Super Zaxxon
13:45 - How to build your own PLA
25:43 - Cost breakdown of the GAL-PLA replacement

--- Video Links

** GAL-PLA Website by Daniël Mantione: (All of the information and files to build your own) **
http://www.freepascal.org/~daniel/c64...

The "PLAin" Truth About the Commodore 64 PLA (and why MOS PLA chips fail so often)
   • #10 'The PLAin Truth About the Commodore 6...

More information on the PLA including timing requirements:
ftp://ftp.zimmers.net/pub/cbm/c64/firmware/C64_PLA_Dissected.pdf

Super Zaxxon Cart provided by Geek With Social Skills:
   / geekwithsocialskills
