Diversity Receiver for Fat shark Dominator goggles.

Product Page
http://amzn.to/2vSs3Hf

Application: FatShark Dominator V1, V2 & V3 goggles and Fatshark HD V1, V2, V3 goggles. For Attitude V3 and teleporter it needs some modification.
Included:
(1) Furious FPV TRUE-D V3 Diversity Receiver System
(1) Plastic Cover
(1) 45 Degree SMA connector
(1) 90 Degree SMA connector

The best gets better with Furious FPV's TRUE-D V3.5 -
https://www.helidirect.com/furious-fp...
With the V3.5, we've refined the TRUE-D with all new ergonomic plastic injection cover and functionality, offering a unrivaled system that is designed to optimize your FatShark experience like no other receiver system available today.

TRUE-D V3.5 utilizes an all new USB port for easy firmware updates, making new firmware installations painless, simple and to the point. Add in additional modules to help dissipate heat, the V3.5 also integrates a built in low voltage buzzer, providing pilots with crucial warning when power gets low.

Unlike average diversity systems that simply alternate channels at predetermined points, the Furious TRUE-D actively searches for the greatest level of signal strength via Smooth Switch technology - choosing the highest strength output for maximum video clarity. And with the new V3.5 system, a higher resolution RSSI is utilized with greater antenna switching capability, offering even better signal resolution & video clarity than any other model on the market today.

New V3.5 Updates:
Ergonomic new plastic injection cover
Better protection mechanic to protect the OLED screen in transportation
New locking system between True-D boards and cover to prevent short circuit
USB plug-in without removing the plastic cover

Features:
True Diversity System Functionality
Smooth Switch Video Switching Technology
Raceband Channel Ready
Multiple Channel Modes - Auto, Manual & Working Modes
Ultra Compact
Built In Easy View LCD Screen for the Ultimate in Setup Ease
Ergonomic & Robust 3 Button Layout
Single Press Button via FatShark Goggles or TRUE-D System
Power On / Power Off Functionality To Conserve Power & Reduce Thermal Loading
Increased RSSI with Better Antenna Switching Algorithm
Built In Low Power Buzzer
Separate Modules To Decrease Thermal Loading
New Micro USB type B Port for Easy Firmware Updates

Specifications:
SMA Style: SMA Jack Connector / Female
Working Frequency: 5.8GHz
Number of Channels: (40) Channels

What Does Diversity Do For Me?
A Diversity receiver system is (2) receivers built into (1) package, allowing the pilot to choose (2) very different antenna systems for maximum levels of video range & clarity.

True Diversity Technology

With (2) receivers working together as (1), your video clarity & overall range is optimized as the TRUE-D Diversity system actively searches for the highest signal quality for maximum video clarity. Add an upgraded & optimized RSSI, and the V3 TRUE-D performs like never before with the very best antenna switching algorithms.

Smooth Switch Video

Instantaneously switching between antennas for optimum signal strength, Smooth Switch technology keeps your head in the race with the very best video quality available.

Updated 3 Button Layout

Stronger, easier and even more functional, we've incorporated an all new 3 button layout, allowing easy access to the entire TRUE-D menu. This allows easy access with the goggles on or off, providing an intuitive and robust interface that is simple and easy to use.

Easy View Simplicity

Make FPV ultra simple with Easy View technology. With Easy View, you are a finger press away from every adjustment you could possibly need, displayed in an easy to ready layout - all with the ease and simplicity of our new 3 button layout.

Push Button Power Up:
TRUE-D V3 can be powered on & off via the stock FatShark button.

Working Mode

Offering you the ability to save (8) total channels, Working Mode makes it easy for you to choose the best channel based upon past preferences for the best known performance.

Manual Mode

Straightforward and to the point, Manual Mode gives you complete control, allowing you to select any of the (40) channels available for optimum FPV.

Auto Mode

Make life simple. With Auto Mode, the TRUE-D system does all the work for you by locking onto the video frequency being used, allowing you to simply fly without fuss or bother.

40 Channel Ready

Optimized with a total of (40) available channels, the TRUE-D covers all the bases, allowing you to use nearly any video transmitter available today.

Ready, Set, Raceband

Ready to race with built in Raceband frequencies, the TRUE-D incorporates Raceband support for track ready application.

Click here: True-v3.5-User-Manual
http://furiousfpv.com/document/Manual...
