Civil 3D - Setting up a title block with dynamic fields for plan production
Автор: Tailwater Limited
Загружено: 2023-12-13
Просмотров: 1690
Using ATTSYNC and ATTDEF commands in Civil 3D to create text boxes for a title block that will be controlled by a sheet set manager. Use this functionality to make plan production more efficient and productive. These steps are some of the first needed to create a template for sheet set plan production.
Chapters
0:00 Introduction
0:11 Creating a sheet set and sheet set manager (SSM).
0:43 Import sheet into sheet set.
0:51 Sheet set custom properties.
1:35 Adding attribute definition fields (ATTDEF).
2:27 Adjusting attribute definition field names.
2:45 Creating a block to get the attribute definitions to function (BLOCK).
3:05 Multiple sheets in a sheet set.
3:24 Editing the attribute definition block (ATTSYNC).
3:51 Adding field to attribute definition block.
4:11 Subscribe and Like :D
