Multispan Universal Temperature Controller: UTC-4202G Product Guide
Автор: Multispan Support
Загружено: 2025-02-08
Просмотров: 3838
This is a comprehensive product guide for the Multispan Universal Temperature Controller (UTC-4202G). The video provides a step-by-step walkthrough of the controller's physical connections, power-up display, and detailed programming/setting configurations. Learn how to set the sensor type (PT100, J/K Type), configure the dual-relay output for Heating, Cooling, and Alarm modes, and understand advanced features like Soaking Mode and PID/ON-OFF control actions.
Chapters:
[00:00] Introduction
[00:09] Wiring and Connections Diagram (Line/Neutral, Relays, SSR, Sensor Input)
[01:03] Power On and Display View (Present Value vs. Set Value)
[01:24] Entering Settings Menu and Password (73)
[01:40] Setting Sensor Type, Output Type, and Relay 1 Mode
[02:06] Soaking Mode Settings (Time, Unit, Memory Option)
[03:19] Control Action (PID/ON-OFF/TP) and Relay 2 Function (with Soaking)
[03:40] Alarm Selection and Limits (SHL/SLL)
[04:26] Relay 2 Mode: Relative Heating Example (Soaking OFF)
[05:33] Dual Mode: Heating/Cooling (Individual Mode) & Relay 2 Delay Time (R2 DL)
[06:11] Conclusion and Final Status
#Multispan #TemperatureController #UTC4202G #ProductGuide #WiringGuide #PIDController #IndustrialAutomation #PT100
