PWM Signal Generator Module 0-150KHZ Frequency 0-100% Duty Cycle Output

Welcome to our channel! In this video, we're going to review and demonstrate the PWM Signal Generator Module with a wide frequency range of 0-150KHz and the ability to adjust the duty cycle from 0% to 100%. Whether you're into electronics, DIY projects, or just curious about signal generators, this module is a versatile tool you'll want to explore.

Key Features:

Frequency Range: 0-150KHz
Duty Cycle Range: 0-100%
Precise and adjustable signal generation
Perfect for pulse-width modulation applications
Compact and easy to use
