EP 007 - Wiring Jeep JL AUX Switches
Автор: American Adventure Lab
Загружено: 2018-06-12
Просмотров: 27478
In this video, I walk through the steps to connect accessories to the factory AUX switches in a 2018+ Jeep Wrangler JL. Also listed below are the wire colors for the factory AUX switches.
I'm wiring in a 37 quart ARB fridge that we use almost daily to keep meals and drinks cold out on the trail. In the hot Moab, Utah climate, the ARB fridge is a life saver. Having the fridge connected to the factory auxillary switches allows for quick and easy operation. Jeep made it easy to connect to the AUX switches. This video illustrates just how easy it is.
Power Probe - https://amzn.to/2l7oIQ4
Fuse panel - https://www.k4switches.com/atc-fuse-b...
ARB Freezer - https://amzn.to/2sSHfnv
12 Volt Power Socket - https://amzn.to/2Mnwf9F
Sign up for our newsletter to get announcements of new products - http://americanadventurelabs.com/.
Jeep JL AUX Switch Wire Colors:
Aux 1 - Brown/Purple
Aux 2 - Green/Purple
Aux 3 - Orange
Aux 4 - Blue/Purple
ACC (Switched on by Ignition) Power - Pink/Orange
Constant Power - Red/White
Ground - Black
