Hummer H2 2005 - Right Power Fold Mirror Arm Repair

How to repair the power-fold mirror drive mechanism on a Hummer H2.

The issues with the power "Fold-In" operation towards the end of the video were related to an reverse wired mirror-glass motor (LHS) Before the arm can move in, the BCU first centralises the mirrors to their mid "Homet" positions. If this cannot be achieved. power "Fold-In" operations are prohibited, however "Fold-Out" operation should always work.

00:00 - Introduction
00:16 - Door Panel and Mirror Arm Removal
00:55 - Power Fold Mirror Arm Examination
02:18 - Power Fold Motor Examination
03:26 - Power Fold Motor Disassembly Stage 1
08:18 - Power Fold Motor Disassembly Stage 2
08:59 - Inside the Clutch Gear Assembly
12:19 - Spring Star Washer Removal
16:58 - Power Fold Motor Full Disassembly Stage 3
18:11 - Clean-Up Operation
21:40 - Fully Cleaned-Up Motor Stage 4
22:41 - Pivot Arm Disassembly Stage 5
23:43 - Pivot-Arm Re-assembly Stage 6
24:00 - Pivot-Arm Re-assembled Stage 7
24:18 - Power Fold Motor Re-assembly Stage 8
27:21 - Power Fold Motor Basic Test
28:13 - Power Fold Motor Re-assembly Complete
28:47 - Power Fold Mirror Arm Re-assembly
30:39 - Issues after Remounting the Power Fold Mirror
30:46 - Inside the "Passenger Door Module"
34:19 - In-Vehicle Testing with a Power Supply
