ECE3400 L43: JFET Bias Equation and Self Biasing (Analog Electronics, Georgia Tech course)
Автор: Lantertronics
Загружено: 2024-10-29
Просмотров: 4264
Описание:
Reference: https://leachlegacy.ece.gatech.edu/ec...
Support this channel via a special purpose donation to the Georgia Tech Foundation (GTF210000920), earmarked for my work: • [OLD] Support This Channel via a Special P...
0:00 -- Introduction
0:32 -- Thevenin equivalents looking out
1:46 -- KVL equation
4:45 -- Quadratic equation
6:04 -- Drain current
6:18 -- Check for saturation
7:27 -- Confusing terminology
7:57 -- Voltage divider bias
8:51 -- Self bias
10:01 -- Choosing emitter resistor
11:54 -- Broader context
12:55 -- JFET current source
13:16 -- Depletion-mode MOSFETs
13:45 -- Vacuum tubes
13:55 -- Component variation
