Ansys Maxwell 3D - Magnetic core saturation current - Simulation and calculations
Автор: Luis_Alvarado
Загружено: 2021-01-10
Просмотров: 13835
Описание:
The saturation of a core is the state at which an increase of magnetic field intesity does not increase the magnetic flux density in the core.
We will simulate a transformer to see at what current the core saturates.
Then we will confirm the simulation calculating the máximum current that the transformer can handle The saturation of a core is the state at which an increase of magnetic field intesity does not increase the magnetic flux density in the core.
We will simulate a transformer to see at what current the core saturates.
Then we will confirm the simulation calculating the máximum current that the transformer can handle
