Direct Conversion Receiver on 20m Band Design1
Автор: RAZI NAJI , YI1RZ
Загружено: 2025-11-15
Просмотров: 628
Описание:
Hello Again my Ham Radio friends
This is Razi Naji ( YI1RZ ) , today in this video I will show you my personal design of Direct Conversion Receiver on 20m Band this time . All the other components of the circuit are the same except C1 and C2 became 56 pF to match the tank circuit for this band .
The Audio Power Amplifier used is LM380N.
Thanks for watching and best 73's
#YI1RZ
#Direct_Conversion_Receiver
#Ham_Radio_Receivers_Circuits
#NE602AN
