How to use ADS1115 ADC module in continuous mode

Автор: Liang-Yu Chen

Загружено: 2022-07-24

Просмотров: 9327

Описание:

Texas Instrument ADS1115 analogue to digital converter is capable of 16-bit resolution and 860Hz sampling rate. However, to achieve 860Hz, we must use continuous mode. This video covers how to set up an ADS1115 with an Arduino in continuous mode.

Time stamps:
00:00 Introduction
02:12 Wiring
03:57 Library introduction
08:12 Continuous mode

Link to library:
https://github.com/adafruit/Adafruit_...
Written version of this tutorial on my blog:
https://light655.github.io/Blog/ADS11...
