How DO you make a Superheated Boiler and Burner for Mini Steam Turbines? 🤔

Full end to end fabrication process for "Jake's Wailer"; A unique scratch built superheated boiler for a mini steam turbine that I had leftover from a previous build.

Steam turbines use an extraordinary amount of steam, so their effective use requires a much more powerful boiler than is normal for piston type live steam models.

All that being said, this build is all about the boiler to power a similar turbine; very similar Turbine builds will follow which feature also the build of the turbine itself so stay tuned!

Thanks for watching

0:00 Preview Steam Up
0:33 Cutting the 42mm Pipe and End Caps
1:09 Drilling ventilation hole (will be used for the pressure valve)
1:38 Tapping the Pressure Valve hole and preparing the washer
2:00 Drilling the coil hole and fitting the coil
2:40 Attaching the legs
2:51 Building the 3 flame spirit burner
3:55 Test Firing to adjust the flames
4:04 Attaching the turbine to the coil
4:45 Fabricating the stilts for the boiler legs
4:51 Fabricating the platform for the turbine
6:16 Fabricating the steel base
7:15 Priming and Enamel Painting the base
7:33 Assembly
8:32 Fixing the turbine to the platform
9:19 Trimming the leg screws
10:03 Making the Burner plate
10:22 Positioning the Metal base on the plinth
11:15 In Memoriam
