Create a dynamic block for cable tray in AutoCAD

For Training & BIM MODELING Work contact me on WhatsApp +918921751895
https://www.bimlane.com/
Providing MEP BIM MODELING SERVICES
BIMLANE is a leading BIM MEP solutions provider, specializing in Building Information Modeling for efficient and precise mechanical, electrical, and plumbing systems. We streamline construction workflows, enhance collaboration, and drive innovation in the AEC industry.
Whether you’re an MEP BIM professional, electrical designer, or Revit enthusiast, this video will help you improve your ELV modeling skills. Don’t forget to like, share, and subscribe for more BIM content!
AutoCAD & REVIT TIPS
In the home tab on the ribbon, in the block panel, choose Create Block
In the Block Definition dialog box, enter a name. If you want to indicate a dynamic block, enter a name like door-DYN.
Specify a basepoint and select objects for the block.
Select Open in Block Editor and OK. The Block editor is where you set up dynamic blocks.
To show the Block Authoring palette, in the ribbon, choose Authoring Palettes.
In the palette, choose the Flip parameter and specify a reflection line.
Choose the Flip action and select the Flip parameter. Then select all objects, including the Flip parameter.
This video also shows you how to test a dynamic block before saving it.

~-~~-~~~-~~-~
