Cable Fault Locator - Digi Bridge

The Digi-Bridge™ is a fully automatic, highly accurate high voltage cable insulation & jacket/sheath testing AND fault location test instrument. Housed in a rugged IP65 pelican type injection molded case, the one-piece fully integrated Digi-Bridge can be used for both cable insulation and cable sheath integrity testing.

Its main function, however, is the precise fault pre-location using the tried and tested bridge fault location technique to locate failures in cable insulation and/or the cable jacket-sheaths.

The Digi-Bridge is particularly useful when traditional thumper impulse reflection (TDR) techniques do not work - for example short circuits and resistive type cable faults. In addition, the instrument can be used for cable/jacket fault pinpointing using the step voltage gradient method for direct buried cables.

The Digi-Bridge is an extremely portable test instrument with a long lasting, integrated, rechargeable battery allowing both AC (shore power) or DC (battery) operation.

Features:
12kV Output Capacity!
30μF Output Capacity!
Very Accurate Fault Pre-Location
Long-Lasting Battery Operation
Ability to Test Very Long Cables
Sunlight Visible Color LCD Display
Find Faults When Traditional Thumper Impulse Reflection Methods Don’t Work
Cable/Jacket Testing, Fault Pre- Location & Pinpointing in a Single Instrument
Compact and Lightweight, yet Rugged & Highly Portable
Easy to Use, Intuitive, Graphical Interface Guides the User
Removable Shielded HV Test Leads for Safer, Easier, and More Flexible Test Setup

Safety:
Automatic Discharge of Cable with Voltage Status Monitoring
Visual Indication of any External Voltage Present on Cable
Capacitive Load Measurement to Avoid Energizing Cables
that cannot be Safely Discharged
Optional Integrated L-ion Battery

Optional Accessories:
702 005DB Transport Case for Digi-Bridge & Accessory Bag
910 003 A-Frame Receiver for Pinpointing Jacket/Sheath Faults
Sales & Support

sales@multiinovasiteknologi.com
multiinovasiteknologi.com@gmail.com
multi.inovasi.teknologi@gmail.com
+62 2254 3224
