Analyzing Transient Response Using Jim Williams' Active Load
Автор: Void Electronics
Загружено: 2024-10-31
Просмотров: 8190
In this video we are analyzing the transient response of two voltage regulators using an active load designed by Jim Williams and published in Application Note 133 by Linear Technology. The video covers the basics of feedback loops, a detailed analysis of the active load's schematic and some experiments. The PCB was designed by @GearAcquisitionSyndrome based on some improvements to Jim's original schematic.
00:00 Intro
00:36 LM78xx regulator basics
01:19 How a linear regulator works
02:51 Proving that the circuit has negative feedback
03:43 Feedback loop limitations
04:38 Basic regulator loads
05:13 Active load circuit analysis
11:27 LM7809 transient response
13:33 1 V 30 A PoL buck transient response
16:28 Outro
AN133: https://www.analog.com/media/en/techn...
Gears and Gear's work on this circuit: • Revisiting Jim Williams (AN133 Simulation,...
