How To Install Pit Boss SMOKE IT Wi-Fi BlueTooth Control Board
Автор: Smoker Grill Girl
Загружено: 2021-04-05
Просмотров: 20302
Get step-by-step instructions on how to install the Pit Boss SMOKE IT Wifi Control Board. The steps are as follows:
Unplug the pellet grill
Remove the eight screws from the bottom of the control panel.
Cut the Wire ties and let the wires hang loosely.
Press the clips on the old control board to loosen them up.
Pull out the old control board
Connect the SMOKE IT Wi-Fi controller using the color-coded wires according to the Pit Boss manual.
Slip the SMOKE IT controller into the slot and snap it into place
Plug in the Pit Boss and ensure everything is working
Don’t forget to test the probes!
Turn off and unplug the grill
Next, connect the Auger Motor Red/White wire from beneath the hopper control panel
Use a wire clip the wires together so they are secured neatly and out of the way of the fans
Screw the bottom cover back onto the control panel
That’s it, you’ve no installed the Pit Boss SMOKE IT Wi-Fi Control board that you can enable via Bluetooth and your Internet.
You just now have to set up the SMOKE It App on your phone, which I will be creating a video and blog post about it in the future.
You can purchase the SMOKE IT WiFi controller by visiting:
Amazon: https://amzn.to/3fGHQ4L
https://SmokerGrillGirl.com
