South Bend Lathe 3 Phase Motor & VFD Installation Part 1

Автор: BasementShopGuy

Загружено: 2016-03-24

Просмотров: 48441

Описание:

Control-Box Parts
www.galco.com
ESTOP: CE4P-10R-02
10K Pot: MT-310B
Switch: M3SS140B20
Box: MEP3-0

Drive Unit:
Lenze SMVector Drive model No: ESV152N02YXB
http://www.wolfautomation.com/product...

Electrical Service Parts:

Plug
http://www.lowes.com/pd_121706-1571-P...

Main power line is SOOW Cord - 10/4.

Outlet & box are 220 (buy one that fits YOUR power needs & VFD)

Shielding Tape:
http://www.stewmac.com/Pickups_and_El...
