Reballing AMD Radeon Graphics Card With HomeMade BGA Rework Station
Автор: Nik Telio
Загружено: 2017-09-23
Просмотров: 715874
This video is showing you how to repair graphics cards AMD-ATI Radeon or Nvidia with BGA problem.
Why Reballing ? The graphics chip is soldered to the board with hundreds small solder balls (BGA) and one or more solder joints crack with time due to the thermal cycle which creates thermal stress (contraction and expansion https://en.wikipedia.org/wiki/Thermal...) and the graphics card stops working, old thermal paste or paste with bad heat conductivity and clogged cooler increase the thermal stress, with this procedure we replace the solder balls and resolder the chip to the board and the graphics card works again.
I prefer reballing over reflow because reflow is not a long term solution and the black screen or artifacts will return again soon. Reballing is more reliable and is the preferred GPU repair method.
Watch also my other videos about Reballing - Rework.
Thanks for watching, don't forget to Like and Subscribe
