LS-DYNA: Common Contact Examples & Cases
Автор: DYNAmore GmbH
Загружено: 2019-05-09
Просмотров: 16843
This LS-DYNA simulation shows common contact scenarios with various contact keywords. LS-DYNA version mpp R9.2 was used for all contact keywords except for the Mortar contact, which used mpp R11.
The LS-DYNA input decks for this example and many more can be downloaded at https://www.dynaexamples.com/show-cas...
Below are the starting points for each of the contact keywords:
AUTOMATIC_GENERAL: SOFT=1 - 0:15
AUTOMATIC_SINGLE_SURFACE: SOFT=1 - 3:52
AUTOMATIC_SINGLE_SURFACE: SOFT=2, SBOPT=3, DEPTH=3 - 7:30
AUTOMATIC_SINGLE_SURFACE: SOFT=2, SBOPT=3, DEPTH=5 - 10:35
AUTOMATIC_SINGLE_SURFACE: SOFT=2, SBOPT=3, DEPTH=35 - 13:20
AUTOMATIC_SINGLE_SURFACE_MORTAR - 15:20
