DESIGN DATA FOR SPRINKLER SYSTEM

Design Code as per IS:15105 2021
IS 15105 : 2021

Area Classification - Moderate Hazard

Area of Operation (AMAO) - 360 M2

Water Aplication Rate (Design Density) - 5 LMP / M2

Theorical Water Demand - 1800 LPM

Minimum Pressure Requirement at Sprinkler - 0.5 Kg/cm2

Sprinkler K- Factor (K Factor for 15mm orfice)

Discharge per sprinkler (Q = K (P)^0.5 ) - 56.75 LPM

Maximum Area of Coverage of Sprinkler - 12 M2

Required No of Sprinklers Under Area of Operation - 30 Nos.

Maximum Velocity DownStream of Valve Flow Monioring Device - 10 M/Sec

Puming Capacity - 2850 LPM or 2850lpm

Pump Head - 7 Kg/cm2


Pressure Available at Remotest Sprinkler Head
Maximum Velocity Any Other Point Expect Valve Flow Monioring Device
Pressure loss calculation - Sprinkler System
Calculation for fire submission purpose (Hydrant & Sprinkler)
Water curtain nozzle Calculation as per IS:15105
Friction Head Loss Calculation
Friction Loss: Pipe Friction Loss is calculated by Hazen Williams Formula,
6.05 x Q1.85x105 / (C1.85 xd4.87)
Pressure Required at Tap-off point
Sprinkler Size and K-Factor
