KTS - 3-Plate PEMB Custom Components for Tekla

This video highlights how to leverage the 3-Plate Custom Components created for Tekla Structures by Keyack Technology Solutions for Metal Building companies that need to rapidly model in assemblies from their detailing shop drawings in order to create 3D models with welding data that can be used by the Cortex software and AGT Robotic Welding Machines.

Chapters:
00:00 - Introduction
01:06 - Web Drawing Dimensions
01:35 - Modify the Grid in Tekla
02:58 - Create Elevation View on Grid
03:57 - Review Web Splice Dimensions
05:37 - Insert 3-Plate Assembly Component
09:48 - Set Leading and Bonus Welds
11:26 - Web Splice Bonus Welds
13:09 - Right 3-Plate Assembly
15:04 - Weld Webs Together
17:29 - Combine the Flanges
18:58 - Left End Plate & CJP Groove Welds
22:58 - End Plate to Web Welds
23:48 - Right End Plate
26:58 - Skew Right End Plate and Web
28:21 - Web Slots
31:53 - Skewed Stiffeners
36:47 - Purlin Girt Flange Brace Connections
41:31 - Offset Side of Connection Plates
42:48 - Bolted Purlin Connections
44:26 - Copy Connections
45:33 - Staggered Welds on Flange Brace Clips
48:12 - Flush Girt Connections to Column Web
54:20 - Save As to Customize Component
55:21 - Lock Component Dialog Box
57:16 - Gage Thickness Data File
58:12 - Conclusion
